Description:
• Temperature measuring range: 30 °C to 45 °C (86 °F to 113 °F), accuracy: 0.1 ° C, deviation: ± 0.5 °C
• Recognition distance: 0.3 to 2 m
• Face mask detection
• Displays temperature measurement results on the authentication page
• 7-inch LCD touch screen,2 Mega pixel wide-angle lens
• Built-in Mifare card reading module
• Face recognition duration ＜ 0.2 s/User
• face recognition accuracy rate ≥ 99%
• 50,000 face capacity, 50,000 card capacity, and 100,000 event capacity
Specification:
System
• Operating System: Linux
Temperature Measurement
• Temperature Range: 30 °C to 45 °C (86 °F to 113 °F)
• Sensor: Vanadium Oxide uncooled sensor
• Resolution: 120 × 160
• Frame Rate: 25 fps
• Measurement Accuracy: 0.1 °C
• Measurement Deviation: ± 0.5 °C, without black body calibration
• Measuring Distance: 0.3 to 2 m
Display
• Screen Size: 7-inch
• Operation Method: Touch screen
Video
• Lens: Dual-lens
• Resolution: 2 MP
• FOV: HFOV= 46°；VFOV=87°
Network
• Wired Network: Support, 10/100/1000 Mbps self-adaptive
Interface
• Network Interface: 1
• Lock Control: 1
• Exit Button: 1
• Door Contact Input: 1
• Alarm Input: 2
• Alarm Output: 1
• TAMPER: 1
• RS-485: 1
• Wiegand: 1
• USB: 2
Capacity
• Face Capacity: 50000
• Card Capacity: 50000
• Event Capacity: 100000
Function
• Face Anti-Spoofing: Support
General
• Power Supply: 12 VDC/2 A
• Working Temperature
0 °C to 50 °C (32 °F to 122 °F)
For temperature measurement: 10 °C to 35 °C (50 °F to 95 °F)
• Working Humidity: 10 to 90% (No condensing)
• Application Environment: Indoor and windless environment use only
